Zinc Metalizing Wire Low Price in India

Zinc Metalizing Wire in Thermal Spray Process

The zinc metalizing wire in the thermal spray gun process is basically the spraying of molten metal onto a surface to provide a coating. To molten zinc wire arc spray gun, the flame spray gun is used. Zinc metalizing wire is melted in a flame with the help of oxygen and acetylene and atomized using compressed air to form a fine spray. When the molten metal contacts the prepared surface of a substrate it rapidly solidifies and forms a coating. This zinc wire thermal spray process is called the cold process relative to the substrate material which is being coated the substrate temperature can be kept low during the process to avoid damage of substrate, metallurgical changes, and distortion to the substrate material. The zinc spray gun process has been extensively used for anti-corrosion coatings and machine element work.

Sand blasting machines are used for surface preparation of components before thermal spray coating. Zinc wire used in a thermal spray gun to provide a coating over the surface of the component to protect it from corrosion. Thermal spray guns are mostly used where all areas are not readily accessible like small, uncoated areas and voids which are better protected by zinc coating than aluminum coating. Zinc metalizing wire is also used as a primer on surfaces, to form electrically conductive surfaces on glass and ceramics will be

Zinc Metalizing Wire Chemical Composition

1. Zinc 99.99%
2. Lead 0.003% Max
3. Cadmium 0.003% Max
4. Tin 0.001% Max
5. Iron 0.005%Max
6. Copper 0.001%

Zinc Metalizing Wire Properties

1. Tensile strength 13000 psi
2. Coating texture 200-350 ra
3. Coating density 36 gm/cc
4. Hardness  Rh 46
5. Melting point 787°C

Zinc Metalizing Wire Applications

1. Corrosion protection on large steel and iron structures like bridges, roadway barriers, poles, offshore structures, and marine structures.
2. Prevent oxidation on steel or iron components such as tanks and gas bottles.
3. EMI and shielding on plastic components (electric arc spray only).
4. Widely used to provide electrical conductance on components like the conductive areas on insulators and capacitor end caps.

Zinc Metalizing Wire Advantages

1. Low investment
2. Easy to operate
3. Wire coating is  cheaper than powder coating
4. Deposition efficiency very high
5. Portable system
6. A preheating facility built-in, unlike arc spraying

Zinc Metalizing Wire Low Price in India

We provide zinc metalizing wire at a low price in India. We also manufacture & supply sand blasting machine, shot blasting machine, sandblasting hopper, grit blasting machine, steel grit, steel shots, glass beads, aluminium oxide, arc spray gun, flame spray gun, thermal spray gun, aluminium metalizing wire, copper metalizing wire, etc. at a low cost for sale.
